SMD5050 LED STRIP LIGHTS MANUFACTURER
LED Strip Lights:
2400K、3000K、4500、6500K
高い演色評価数(CRI>80 CRI>90)
高輝度: 2400lm/m (単線 LED ストリップ用)
入力DC12V、DC24V定電圧版
LED ブランド: Epistar 5050 LED
SMD5050 Magic Color Series
Lightstec SMD 5050 LED strip light Magic color series is SMD Epistar 5050 RGB type with DC12V and DC24V constant voltage input.IP33 & IP65 waterproof. There are 30Leds per meter and 60Leds per meter version. The minimum cuttable length is 50mm and 100mm, and the PCB width is 10mm.
SMD5050 Single Color Series
Lightstec SMD 5050 LED strip light Single color series is hight brightness led strip light.SMD Epistar 5050 type with DC12V and DC24V constant voltage input.IP33, IP55, IP65 and IP67 waterproof. There are 30Leds per meter, 60Leds per meter and 120Leds per meter version, PCB width is 10mm. Customized design is warmly welcome.
SMD5050 RGB Color Series
Lightstec SMD 5050 LED strip light RGB color series is hight brightness led strip light. SMD Epistar 5050 RGB type with DC12V and DC24V constant voltage input.IP33, IP55, IP65 and IP67 waterproof. There are 30Leds per meter and 60Leds per meter version. The Minimum cuttable length is 50mm and 100mm, and the PCB width is 10mm.
SMD5050 RGBW Color Series
Lightstec SMD 5050 LED strip light RGBW color series is SMD Epistar 5050 type with DC12V and DC24V constant voltage input.IP33, IP55, IP65 waterproof. There are 60Leds per meter and 120Leds per meter version. The Minimum cuttable length is 50mm, 100mm and 166.6mm, the PCB width is 12mm or 15mm.
5050 LED Strip Light Accessories
非防水タイプ LEDストリップライトコネクタ
+ 2ピン-コーナー-単色コネクタ
2ピンワイヤレス単色コネクタ
L-2pin-コーナー-単色コネクタ
T-2pin-コーナー-単色コネクタ
2ピンダブルヘッドコネクタ単色
メス-オス-コネクタ
2ピンワイヤレスコネクタn8bb
LED ストリップ ホールド クリップ
防水タイプ LED ストリップ ライト コネクタ
2pin 無線コネクタ 単色防水
2ピンシングルヘッドコネクター防水
LED防水DCコネクタ防水
シリコンクリップ
How To Select SMD5050 Led Strip Light? (The Definitive Buying Guide)
Lightstec is one of the best SMD5050 LED light strip manufacturer in China. When you are sourcing SMD5050 led strip light and want to import SMD5050 led strip light from China, This is the right place you are.
In this guide, we will teach you to be an expert in SMD5050 led strip light. And this will help you find a reliable China SMD5050 led strip light manufacturer
What is SMD5050 led strip light?
SMD5050 led strip light is made by SMD5050 led chips and SMT in a PCB board.
Normally, SMD5050 has 3 chips in one led housing.
0.21W/Pcs,18-20lm/pcs
SMD5050 can make many functions led strip lights.
It has a single color, RGB color change, RGB+W 4 color in one led housing,RGB+CCT 5 color in one
And constant current IC inside LED chips, addressable IC inside led.
Does SMD5050 led strip light color temperature change?
If you need led strip light color change, you need two color temperatures led in one led strip light.
Normally, CCT change led strip light to have 2 color temperature led.
One is lower CCT-2700k, one is higher CCT-6500K.
Then you can use a CCT controller to change the color temperature.
But normally, CCT change led strip light is using SMD2835 or SMD3528.
Because the SMD5050 size is bigger and has 6 solder pan.
When mix the color is not good than SMD2835.
Does SMD5050 led strip light have CRI>90 versions?
The higher CRI, the items will more true compare with seeing under sunlight.
At the beginning of the led light industrial, the CRI is low. Approx 60.
But now CRI can higher reach 95.
We have CRI>80, CRI>90 and CRI>95 SMD5050 led strip light.
This is good for high request lighting projects.
Do you have waterproof SMD5050 led strip light?
Waterproof led strip light is better for using in some humid and raining place.
Just like a shower room, swimming pool, veranda, etc.
There is a different level of waterproof design for different places.
IP20 / IP33 - 防水ではありません。屋内でのみ使用してください。
IP55-シリコン表面落下防水。これにより、照明のビジョンが変わります。うちも室内で使ってます。
IP65 - シリコンチューブ防水。雨が降っているときに使用することをお勧めしますが、水に落とさないでください。
IP67/68 - スイミングプールにも使用可能
についての他の投稿を確認できます 防水LEDストリップライト。
Can I dim my SMD5050 led strip light?
All of our led strip light is constant current led strip light.
Our SMD5050 led strip light to have DC12V and DC24V.
We can use the 0-10V dimmable power supply to dim SMD5050 led strip light
We can use Dali dimmable driver to dim SMD5050 led strip light
We can use Triac dimmable power supply to dim SMD5050 led strip light
And we can use many kinds of the dimmable led controller to dim tape light
Here is a post can you can learn a lot from our post: LEDストリップライトを暗くする方法
SMD5050 led strip light VS SMD3528 led strip light
SMD5050 is 0.2w/pcs,and 20 lumens pcs.
SMD3528 is 0.06w/pcs,and 7lumens pcs.
So if the same quantity led per meter, then SMD5050 led strip light will more brightness.
We can see a video to know the different compare SMD5050 led strip light with SMD3528 led strip light.
Can I use SMD5050 led strip light as a lighting source to make led linear light?
Normally, led linear light is made by strip light, led aluminum profile and led driver.
For some cabinet light, the profile is small. Then means the led is near the cover.
If the led less in one meter, then when lighting you will see dot from the profile cover.
So we suggest using SMD5050 led strip light in big LEDアルミニウムプロファイル as lighting source.
Do you have SMD5050 color change led strip light?
SMD5050 led strip light to have some kinds of color change led strip light not only a single color.
SMD5050 RGB led strip light
This led have Red, Green, Blue 3 chips in one led.
And use the controller can change different colors.
SMD5050 rgb+w led strip light
This led have 4 chips in one led housing. Red, Green, Blue, white color.
Also, have RGBW led controller to change the color.
SMD5050 rgb+cct led strip light
This led have 5 chips in one led housing. Red, Green, Blue, white, warm white.
This has RGB+CCT led controller to change the strip light colors.
How to connect SMD5050 led strip light to the power supply?
When we are using the SMD5050 led strip light, we need to use a led power supply.
一部の照明プロジェクトで調光機能が必要な場合は、調光可能な電源または調光可能なコントローラーに接続する必要もあります。
ここではストリップライトを電源に接続する方法を説明します。
